Why so many people choose our Metal Core PCB?

Views: 0     Author: Site Editor     Publish Time: 2022-06-03      Origin: Site


facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
whatsapp sharing button
sharethis sharing button

Metal Core PCBs also called MCPCBs, whose substrate layer is a metal base. The most common metals of MCPCBs used are aluminum, copper, and steel alloy. Aluminum-based PCBs are the most cost-effective; they exist good heat conductivity and thermal dissipation ability at low prices. Copper-based PCBs perform better than aluminum, but the price is higher. Steel-based PCBs are harder than the first two materials, while with a lower heat conductivity. Metal PCBs are known as their excellent thermal dissipation. Along with the improvement of electronics’ specifications, the circuits have been developed towards miniaturization, lightweight, multi-function, and high performance. Therefore, thermal issues become vital problems to affect the stability and reliability of electronic products. Metal Core PCBs are effective solutions for thermal problems in high-density circuits when customers do the PCB assembly prototyping and mass productions.

Here is the content:

The benefits of the Metal Core PCBs:

1.Excellent thermal dissipation

2.Good dimensional stability

3.Good heat dissipation of Metal Core PCBs makes them less prone to high temperature, which causes less distortion during signal transportation.

Excellent thermal dissipation

Thermal conductivity refers to the thermal performance parameters of a material. The thermal conductivity of Metal Core PCBs like aluminum PCBs exhibits higher than other PCBs that use FR4 and CEM3 as the substrates. High thermal conductivity makes Metal Core PCBs have an excellent heat dissipation ability. The heat produced by ICs and components will be removed quickly, which helps to reduce the heat damage of the components and prolong the service life of the products, as well as improve the performance.

Good dimensional stability

Aluminum PCBs and copper PCBs have high CTE (the coefficient of thermal expansion). CTE refers to describe the expansion or contraction of material on heating. High CTE means the PCBs have a good thermal expansibility, and the board size will be little changed under the high temperature when compared to the normal FR4.

Good heat dissipation of Metal Core PCBs makes them less prone to high temperature, which causes less distortion during signal transportation.

The advantages mentioned above make Metal Core PCBs ideal solutions in many applications, such as power converters, lightings, photovoltaic, backlight applications, automotive LED applications, home appliances, and so on. Aluminum-based PCB is the most common type of Metal Core PCBs for its cost advantage. Especially in solid-state lighting, aluminum PCBs help achieve higher lighting levels with less quantity of LED.

The copper foil thickness of MCPCB can be 1oz to 10oz, and the metal core thickness of the boards usually is 30mil to 125mil. We offer all types of Metal Core PCBs, and just contact us if you need thicker or thinner substrates. We will always keep our capabilities and equipment standards with the pace of advanced levels to provide customers with the best services.  Our company is supplying industry-leading clients based on trusted relationships. Collectively, we focus on delivering reliable products and satisfactory service to all local and global clients. In general, we have a wide and good reputation for the use, quality and cost-performance of our products. Our company group is committed to providing customers with the best products and the best value, and build the best trust with customers to meet every specific need!

Boyunfa is a printed circuit board  company, Located in Shenzhen,520 employees,16000 square feet, Who have offered  PCB Manufacturing Service for more than 10 years.With the state-of-the-art technologies we employ, along with our highly trained workforce we are able to ensure that every PCB we provide matches your design requirements.
