Aluminum Deck pcb clone for selfie light

Layer:2
Material:FR-4
Board thickness:1.6mm
Copper Thinckness:1OZ
Sold mask:Green
Silk-screen:White
Availability:
Quantity:
sharethis sharing button

Although the single sided PCB is the most basic and the start point of printed circuit technology and indeed, the start point of the invention, it still plays a major role in the industry.

The PCB was invented to give a good mechanical base for components and by using printing to produce the tracks allowed repeatability of interconnections in volume.

It also means reliability of connections compared to handwiring and another big benefit is ease of assembly production of an electronic device in volume.

In through hole device technology, it does have its limitations in interconnecting large numbers of components as all the tracks are on one side but it is a cheap way of gaining all the above benefits on more simple circuits.

Due to surface finishes like Lead free hot air level, Nickel Gold and organic surface protection, single sided boards can used for surface mount devices as well as through hole. Using this technology, although the PCBS are relatively simple, they can still be used in very complex devices. This is quite often apparent on LED technology.
