Why you should choose the flexible PCB?

Views: 0     Author: Site Editor     Publish Time: 2022-06-10      Origin: Site

Inquire

facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
whatsapp sharing button
sharethis sharing button

The flexible circuits, or most commonly known as flexible PCBs, are often a misleading term in the communication and electronics field. Generally, a PCB made of a flexible insulating substrate is called a flexible PCB or a flexible PCB. Although it is named as a flexible printed circuit, the FPCB differs in manufacturing, fabrication, design, and application from that of regular PCBs. Flexible PCBs are typically used in small electronic products like cellphones, tablets, cameras, video recorders and other similar smaller gadgets on the market today.

The flexible PCB meets the needs of today's electronic products in the direction of high density and high reliability, miniaturization, and light weight. It also fulfills the strict economic requirements and the demands of market and technology competition. Next, we gonna tell you why you should choose the flexible PCB.

Here are the advantages of flexible printed circuit boards:

1. The convenience of the flexible PCB

2. The low cost and price of the flexible PCB

3. The characteristic of friendly-environment of the flexible PCB

1. The convenience of the flexible PCB

Rigid-flex printed circuit boards feature a hybrid circuit board design that combines the malleability of flexible circuits with the rigidity of hard boards. Their sulting component is hard at some points and flexible at others, which allows it to be folded or flexed as needed to fit the electronic configuration. In the assembly line of components, the conductor cross-section of the flexible PCB is thinner and flat compared to the conductive cables. The flexible PCB reduces the size of the wire and can be formed along with the casing, making the structure of the device more compact and reasonable, and reducing the size of the assembly. volume. Compared with rigid PCB, the area of a flexible PCB can be saved by 60~90%.

2. The low cost and price of the flexible PCB

Using the flexible PCB to install the connection can reduce the total cost. The reasons why the flexible PCB can do this list below. First, The application of flexible PCB simplifies the structural design, it can be directly adhered to the component, reducing the clamp and its fixing parts. Second, due to the consistency of the various parameters of the flexible PCB, the overall termination is implemented, which eliminates the errors and rework that often occur when the cable conductors are installed and connected. So the replacement of the flexible PCB is more convenient. That is the other reason for its low cost.

3. The characteristic of friendly-environment of the flexible PCB

A significant advantage of the flexible PCB is that it can be more easily routed and connected in three-dimensional space, and can also be rolled or folded for use. As long as it is curled within the allowable radius of curvature, it can withstand thousands to tens of thousands of times without being damaged. In this way, waste of materials can be reduced. So, it’s a good choice to use the flexible PCB.

Our company, boyunfa, is committed to providing customers with the best products and the best value. With the flexible PCB, you can bend your PCB so that it fits the space you have available. In other words, you no longer have to build your device around your PCB. Instead, the PCB will fit the device the way you want it to. We sincerely invite you to visit our website online or contact us on the phone.

Please believe us, we are glad to make you satisfied.
